Common applications · FTP-300
IoT Installations
FTP-300 has built-in IoT capabilities including remote monitoring capabilities. The dashboard aggregates data points from connected power units, and presents key performance indicators — like temperature and connection status — in a clear and intuitive way.
- Deployed in
- location_onSpain
- location_onEurope
Solutions
How the FTP-300 powers IoT Installations
In the deployed solution, the Galgus Wi-Fi access point is connected to the FTP-300 via one of the two Ethernet ports for 48V power (only). Internet access is enabled via the built-in SIM card for mobile connectivity. The solution doesn’t require separate PoE injectors and there is a minimum of cabling required. It can be deployed anywhere there is access to a mobile network.
From smart city Wi-Fi to remote surveillance, our FTP-300 unit integrates seamlessly with Meraki deployments — even in harsh, off-grid locations.
Product features
FTP-300
-
monitoring
Remote power monitoring
FTP-300 has built-in IoT capabilities including remote monitoring capabilities. The dashboard aggregates data points from connected power units, and presents key performance indicators — like temperature and connection status — in a clear and intuitive way.
-
hub
Versatile
Having a separate DC output and two back-to-back connected data connectors, which individually can be PoE enabled, FTP-300 can be used in multiple applications such as powering wireless access points, surveillance cameras, wireless bridges and repeaters, cable modems, and remote lighting systems.
-
construction
Deploy and forget
FTP-300 is designed to work in harsh and remote locations. To conserve battery longevity, FTP-300 turns off when power levels become too low to sustain further usage. When the charge level is back above the threshold, FTP-300 automatically turns on again. No human intervention required.
Specifications
All specifications arrow_forward- Output terminals
2 x RJ45 data ports
1 x RJ45 port for IoT (only)
1 x DC cable terminal
- Output power
Total maximum output power (PoE + AUX): 30 Watt
2 x 0/24/48 VDC selectable Passive PoE
48 VDC - Max Power 30W as PSE
24 VDC - Max Power 30W as PSE (15W/port)
1 x AUX + 24 VDC - Max Power 30 W
- Operating temperature
Charging: +0°C to +45°C / +32°F to +113°F
Discharging: -20°C to +60°C / -4°F to +140°F
- Box IP-Rating
IP65
